Features
Lift & Controls
- Electronic hydraulic power-lift system
- Touch-pad raise and lower controls
- Manual mode for non-powered use
- Modular hydraulic actuator and power pack
Patient
- Adjustable pneumatic backrest
- Shock frame
- One-hand swing-down siderails
- Locking mattress and patient restraints
Frame
- Anodized tubing
- Multipurpose drop frame
- Adjustable foot-end lift bar
- Foot-end lead handle
Mobility & Loading
- Infinite height adjustment, 13" to 41"
- Loads at any height up to 33"
- Four 6" swivel wheels, two with locks
Specifications
| General | |
| Type | Powered hydraulic ambulance cot |
| Weight capacity | 700 lb |
| Cot weight | 133 lb (with power pack, without mattress and restraints) |
| Operators required | 2 |
| Control unit | 24 V DC |
| Charging time | 3 hours |
| Dimensions | |
| Length | 83" maximum / 61" minimum |
| Patient surface length | 79" |
| Width | 24" overall / 16" patient surface |
| Height | Infinite positioning, 13" to 41" |
| Loading height | Up to 33" |
| Wheels | 6" |
| Compatible Fastener Systems | |
| Ferno Model 175 Series | Fastener not included |
| Stat Trac | Requires Stat Trac compatibility kit |
